Your location : Homepage > Product > mining machine > Sprayer
Sprayer

411 shotcrete machine

The spraying machine is suitable for the spraying range: cement mortar, putty powder, paint, latex paint, real stone paint, thermal insulation mortar, waterproof material, fireproof material, thermal insulation material, sound-absorbing material and other water-soluble materials 1. Adopt full copper clad national standard motor with stable performance. Reject any non-standard aluminum-clad motor 2. The connection between the spray gun and the feeding tube can be rotated for easy operation. 3. High construction efficiency and good quality. And small size, easy to carry on-site, 4. The sealant sleeve is made of black rubber, which is wear-resistant and anti-corrosion, and adds a protective umbrella to the equipment.

model411 diesel sprayer
power pressure6mpa
power output12 hp
Spray area150m²/h
conveying distance20m
delivery flow2m³/h
Hopper capacity80L
Maximum passing particles8mm
Maximum vertical height can be compressed15m
Maximum parallel length can be compressed30m
Dimensions170*90*110cm
machine weight290kg

411 shotcrete machine(圖1)

model411 Electric Shotcrete Machine
Voltage220v/380v
Motor Power4kw
Spray area150m²/h
Air pump power2.2kw
delivery flow2m³/h
work pressure3-6mp
Maximum passing particles4mm
Maximum vertical height can be compressed15m
Maximum parallel length can be compressed30m
Dimensions155*42*90cm
machine weight160kg

411 shotcrete machine(圖2)
