| Model | HZS-50 Simple Concrete Mixing Plant |
| Productivity | 50m³/h |
| Mixing host model | JS1000型 |
| Mixing host power | 37kw |
| Cycle period | 60s |
| Mixer nominal capacity | 1000L |
| Maximum aggregate size | φ80mm |
| Capacity of powder silo | 2x100t |
| Batching capacity of the batching station | 100m³/n |
| Aggregate silo capacity | 6m³x3 |
| Aggregate type | 3 |
| Aggregate belt conveyor productivity | 100t/h |
| Maximum production rate of screw conveyor | 40t/h |
| Discharge height | 3.8m |
| installed capacity | 120kw |
| Aggregate weighing range and accuracy | （0~3000kg）±2％ |
| Cement weighing range and accuracy | （0~1500kg）±1％ |
| Weighing range and accuracy of fly ash | （0~1500kg）±1％ |
| Water weighing range and accuracy | （0~600kg）±1％ |
| Admixture weighing range and accuracy | （0~150kg）±1％ |
