HZS concrete mixing plant

HZS180 (3000+4 silos) concrete mixing plant

The HZS180 concrete mixing station adopts an integrated design, which has the advantages of high efficiency, energy conservation and environmental protection, accurate measurement, intelligent control, convenient operation, stability and reliability, and high cost-effectiveness. Widely used in large and medium-sized prefabricated component factories, as well as industrial and civil construction projects such as highways, bridges, water conservancy, docks, etc

ModelHZS-180 concrete mixing plant
Productivity180m³/h
Mixing host modelJS3000型
Mixing host power55kw*2
Cycle period60s
Mixer nominal capacity3000L
Maximum aggregate sizeφ80mm
Capacity of powder silo4x200t
Batching capacity of the batching station300m³/h
Aggregate silo capacity25m³x4
Aggregate belt conveyor productivity300m³/h
Maximum production rate of screw conveyor120t/h
Discharge height4m
installed capacity295kw
Aggregate weighing range and accuracy(0~2000kg)±2%
Cement weighing range and accuracy(0~1000kg)±1%
Weighing range and accuracy of fly ash(0~1000kg)±1%
Water weighing range and accuracy(0~500kg)±1%
Admixture weighing range and accuracy(0~100kg)±1%

HZS180 (3000+4 silos) concrete mixing plant(圖1)

HZS180 (3000+4 silos) concrete mixing plant(圖2)

HZS180 (3000+4 silos) concrete mixing plant(圖3)

HZS180 (3000+4 silos) concrete mixing plant(圖4)
