1. The piston reciprocates once to implement the suction and discharge of two liquids 2. Hydraulic pumping system, the hydraulic drive machine works reliably and the pumping pressure is high 3. Customized universal wheels are more convenient for walking and moving 4, compact structure can also be used in special workplaces
| model | SY90-125 type double liquid grouting pump |
| System pressure | 0-16Mpa (adjustable) |
| Workflow | 4-5m3/h |
| work pressure | 0-8Mpa (adjustable) |
| Cylinder diameter | 110mm |
| conveying distance | Vertical 80m Horizontal 300m |
| Number of cylinders | 2 |
| suction height | 2m |
| Motor Power | 11kw |
