sand slurry pump

HSJB-6 Mortar Pump

HSJB-6 mortar pump has the characteristics of high working pressure, large flow, high production efficiency, convenient operation, safety and reliability, flexible movement, compact structure and easy maintenance. 1. The pump has high rated output pressure, fast boost, large displacement, high efficiency, easy to move, easy to use and maintain 2. Double-cylinder double-acting, the piston reciprocates once, which can realize the suction and discharge of two liquids 3. Hydraulic drive, stable performance, reliable work, high pressure, simple operation 4. Non-contact reversing mechanism, effectively reduce the failure rate and machine noise

modelHSJB-6 Mortar Pump
Mortar delivery volume6㎡/h
work pressure0-5Mpa
power7.5kw
Motor speed1420r/min
Number of plunger cylinderssingle cylinder
Inner diameter of grouting hoseφ32/38mm
Inner diameter of feeding hoseφ64mm
Mortar ratio1:1.2:0.48 (cement:sand:water)
Dimensions1300X800X900mm
Total Weight300kg

HSJB-6 Mortar Pump(圖1)

HSJB-6 Mortar Pump(圖2)

HSJB-6 Mortar Pump(圖3)

HSJB-6 Mortar Pump(圖4)

HSJB-6 Mortar Pump(圖5)
