Your location : Homepage > Product > road machinery > Laser leveler
Laser leveler

LS-325 laser leveling machine

The laser leveling machine is developed according to the increasing demand of modern industrial plants, large shopping malls, warehouses and other large-area cement concrete floors for ground quality such as strength, flatness, levelness, etc., which can greatly improve the concrete quality. The flatness and compactness of the concrete floor can be extended to prolong the service life of the concrete floor. Product performance ● Imported servo drive system, stable running, accurate speed regulation, strong overload capacity ● German Leica laser system, extremely high working accuracy and reliability ● All-electric drive, low fuel consumption per square meter and low operating cost

product typeproduct name2 Wheel Electric Drive Concrete Laser Leveler
Product numberLS-325
power systemmodelHonda GX160 generator set
typeGasoline, single-cylinder, four-stroke, air-cooled
Lubricant quantity (L)0.58
Fuel tank volume (L)15
Power(kw)2
Voltage (V)220AC
leveling systemleveling headIndependent suspension, center swing
Flattening width(mm)2500
Paving methodScraper flat
Paving thickness (mm)30-300
Vibration system control methodVibration motor
Vibration force (kg)100
Vibration frequency (Hz)50
Laser systemLaser system control modeLaser scanning + high-sensitivity DC actuator
Laser system control effectplane, slope

LS-325 laser leveling machine(圖1)

LS-325 laser leveling machine(圖2)
