Your location : Homepage > Product > Floor machinery > car trowel
car trowel

Type 100 Jiezhou hydraulic driving trowel

It is suitable for large and small construction sites, and can be used for indoor and outdoor troweling operations. It is widely used in high-standard workshops, warehouses, squares, airports, parking lots, pavements, road and bridge maintenance, concrete surface grouting and smoothing. It is one of the important equipment in concrete construction. Two pulping discs can be installed at the same time for rapid pulping, mechanical steering operation system, responsive and easy to control. 1. The low center of gravity design makes the machine run smoothly and flexibly 2. The surface is sprayed with plastic, beautiful and beautiful, anti-rust and corrosion-resistant 3. The gearbox is designed with large modulus, aluminum alloy box, maintenance-free, and long service life 4. The trowel support The arm is made of super-large diameter carbon structural steel that has undergone strict heat treatment, with high strength.

Machine powerFour-stroke air-cooled gasoline engine
ModelGX690
Output Power17.9kw/24hp
Maximum speed3600rpm
Fueltank capacity12L
Working diameterL1890*W916mm
Rotating speed150-155rpm
Angle adjustmenthydraulic
DimensionsL198*W102*H150cm
Total Weight425kg

Type 100 Jiezhou hydraulic driving trowel(圖1)
